Z200 Series Piston Gauge

  • Cost effective and reliable when only local indication is needed
  • Simple and compact design
  • Easy to read dial gauge eliminates accumulated errors of two gauge installation
  • High operating pressures up to 6,000 Psig
  • Ranges up to 150 Psid
  • Over pressure safe from either side to maximum working pressure
  • Indicating mechanism isolated from pressure chamber
  • Wide applications in air, gas and liquid media
Accuracy: +2% of the FSD (Ascending)
Migration: Minor from high to low port
0-10, 25, 50, 75, 100 Psid
First marking on the scale:
20% of FSD
Sensing element:
Wetted parts: Body material, SS spring, ceramic magnet & seals
Case materialr: Engineeed polymer
Dial size: 2.5" (square), 4.5" (round)
Mounting: Direct, front flange, 2" pipe & surface mounting
Maximum working pressure: 3000 Psig for Aluminum & Brass, 6000 Psig for SS
Maximum process temperature: 93° C (200° F)
Body material:
Aluminum & 316 SS
Plexiglass (acrylic)
Connection: 1/4" NPT(F) Std.
Over range protection:
Up to the MAWP from high & low side
Protecting for gauge and switch:
NEMA-4X / IP65
